Generel information

ADI varenummer

TI-BG62I

Mærke

TRENDnet

Producent

TRENDnet

Producentens varenummer

TI-BG62I

Produktlinie

Industrial

Produktmodel

TI-BG62i

Produktnavn

6-Port Industrial Gigabit L2+ Managed PoE++ DIN-Rail Switch

Produkttype

Ethernet Switch

Tekniske oplysninger

Medietype understøttet

Optical Fiber, Twisted Pair

Strømforbrug

20W

Certificeringer

CE-mærkning

Compliant

TAA-overensstemmelse

Yes

Fysiske egenskaber

Bredde

170 mm

Dybde

118 mm

Farve

Sort

Højde

50 mm

Materiale

Metal

Garanti

Begrænset garanti

3 år

Generel information

vægt

956g

Grænseflader/udvidelsesstik

Modulær

Yes

Netværk (RJ-45)

Yes

Samlet antal netværksporte

6

I/O-udvidelser

Antal SFP + Slots

2

Antal SFP-slots

2

Antal udvidelsesslot

2

Udvidelsespladstype

SFP

Medie & Performance

Netværksteknologi

1000Base-FX, 1000Base-T

Netværk og kommunikation

Ethernet teknologi

Gigabit Ethernet

Lag understøttet

3

Netværksstandarder

IEEE 802.1ab, IEEE 802.1ax, IEEE 802.1d, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

Produktinformation

Monteringstype

DIN Rail Mount, Enclosure

Strømbeskrivelse

Input Volt

48V DC, 57V DC

PoE (RJ-45) Port

Yes

PoE Budget

360W

Redundant strømforsyning

Yes

Stik/forbindelsestype

Terminal Block

Strømkilde

AC

Styring og protokoller

medgørlig

Yes

Diverse

Funktioner

12Gbps switching capacity, 2 x SFP slots, 360W PoE power budget, 4 x Gigabit PoE ports, 802.1p/DSCP/Queue Scheduling (SPQ/WRR) QoS support, 802.1Q/Q-in-Q VLAN and IGMP Snooping/MLD/MVR support, Alarm output triggered by power failure, Bandwidth control per port, CLI (Console/Telnet/SSH), Web (HTTP/HTTPS), SNMP v1/2c/3 management, Dual inputs provide redundant power with overload current protection, Fast PoE remembers per port PoE power draw of connected devices at booting, Hardened IP30 rated metal housing, IEEE 802.1p QoS with queue scheduling support, Includes DIN-rail mounting bracket, Operating temperature range of -40 to 75 deg C (-40 to 167 deg F), Perpetual PoE provides PoE power to connected devices at booting, PoE alive check restarts unresponsive PoE powered devices, Power supply sold separately (model: TI-S48048), Supports 1000Base-FX fiber SFP modules, Supports Ethernet Ring Protection Switching (ERPSv2), Supports LACP, STP/RSTP, VLAN and IGMP Snooping

Miljøcertificering

CE, Freefall (IEC 60068-2-32), Shock (IEC 60068-2-27), Vibration (IEC 60068-2-6)

Pakkeindhold

TI-BG62i
Quick Installation Guide
Removable terminal block
DIN rail mounting bracket

TRENDnet TI-BG62I 6-Port Industrial Gigabit L2 Managed PoE DIN-Rail Switch, 2-SFP-porte, 360W, Sort
